WANAS COMBO 1330 H
The WANAS COMBO 1330 H heat recovery unit is a unique ventilation unit combining four key functions: ventilation, humidification, heating, and cooling. The unit is designed for ventilation of single-family homes and commercial buildings.
1330 m3/h
600 m2
A
34,2 dBA
27-674 W
Pa 100
3000 W
230/50 V/Hz
ePM 10 50%
3D model
Advanced control functions and user comfort
The WANAS COMBO 1330H heat recovery unit offers innovative technologies that provide comfort and full control over the ventilation system. The maxiControl humidity sensor automatically adjusts the humidity level in the room, and the DISPLAY V2 touchscreen allows for easy operation. Additionally, the WANAS MOBILE CONTROL module allows you to manage the system from anywhere using a mobile app. This means full control over ventilation, humidification, cooling, and heating from your phone.
Highest efficiency heat exchanger
The aluminum cross-counterflow heat exchanger is an ideal solution for both single-family homes and commercial buildings, ensuring optimal thermal comfort and reduced energy costs. It’s the choice for those who value modern and durable ventilation technologies.
Evaporative humidifier
The WANAS Combo 1330H evaporative humidifier in the heat recovery unit is an innovative solution that ensures optimal indoor humidity levels while improving air quality. The evaporative humidifier utilizes the natural process of water evaporation, which is the healthiest and most effective way to humidify air. Water is distributed on a special evaporative mat through which air flows. During this process, the water evaporates, increasing the air humidity without the risk of over-saturated moisture.
The air is always under control
The XF system ensures precise airflow balancing in the ventilation system. It monitors and automatically adjusts the operation of supply and exhaust fans in real time to maintain airflow balance within the system. Four measurement points are installed on the fan, ensuring highly accurate airflow measurement. Our system stands out from the competition by displaying airflow in m³/h in real time.
BYPASS
The air handling unit is equipped with a bypass, which manages airflow, allowing for cooling of rooms in the summer by bypassing the heat recovery process. This allows the system to direct cooler outside air directly into the building, naturally lowering room temperatures on cool nights or less hot days. The automatic bypass operates maintenance-free – the system independently assesses weather conditions and adjusts its operating mode to ensure user comfort and minimize energy consumption. What distinguishes our solution from others on the market is that we can automatically set a higher airflow when the bypass is opened, quickly improving comfort in the building. For example, the unit operates at minimum airflow, and when the outside temperature is cooler, the bypass opens, increasing the unit’s efficiency by 100%.
SMART HEATER
The WANAS COMBO heat recovery unit is equipped with a smart heater that automatically adjusts its heating power to current conditions, such as outside temperature and airflow. This automatic regulation ensures optimal heat exchanger protection. The unit’s installed heater only consumes 3000 W, which is still its power consumption even in extremely unfavorable outdoor conditions. During most operating hours, the power will be much lower.
Modbus RTU
MODBUS RTU is a reliable, universal serial communication protocol that enables data exchange between the heat recovery unit and external control systems. Its use allows for integration of our device with any intelligent external building management systems, such as Sinum, Lexon, Grenton, etc. We can control the heat recovery unit from an external system.
Water and freon heaters and coolers
The WANAS COMBO heat recovery unit can be equipped with a water or freon heater/cooler, significantly increasing its heating or cooling capabilities. Water heater/coolers use water as the heating medium, while freon versions operate on a refrigerant basis, providing fast and effective heating or cooling. Integrating these devices ensures high energy efficiency and improves indoor thermal comfort, adapting the system to changing outdoor conditions and ensuring energy savings year-round.
Your home, your rules – Smart home with an internet module
The WANAS Mobile Control W-25 Wi-Fi internet module enables remote control of WANAS ventilators using a smartphone, tablet, or computer. These modules allow for real-time management of the ventilator’s operation, including changing operating modes, adjusting ventilation intensity, and setting operating schedules. Users also have access to key information such as airflow, temperature, humidity, and filter status, making it easier to monitor indoor air quality.
The modules send notifications about filter replacement, system malfunctions, and service needs, improving system reliability.
Expandable – adaptable to your needs
Aggregate
The WANAS COMBO heat recovery unit can be equipped with a unit, which significantly expands its functionality by adding the ability to effectively manage indoor temperature. The unit acts as an additional source of heating or cooling, ensuring optimal temperature control, especially in extreme weather conditions. Integration with the ventilation system allows for quick adaptation to changing conditions, ensuring comfort and energy savings year-round.
Buffer
By adding a buffer to the WANAS COMBO system, energy can be used more efficiently. The buffer stores heat or cold, allowing the system to adapt to changing energy demands. This buffer stabilizes room temperatures, eliminating unwanted thermal fluctuations and optimizing energy consumption, which translates into lower operating costs and improved user comfort.
Patented solution
WANAS COMBO heat recovery units are exceptional devices distinguished by their unique, patented solutions. Innovative ventilation and humidification technologies not only ensure a healthy indoor climate but also minimize energy consumption, translating into operational savings. Thanks to the use of modern materials and advanced design, these devices support eco-friendly operation, ensuring improved air quality and user comfort in every room.
Are you interested in the product?
Our team will answer all your questions and help you choose the right solution.
If you’re an installer, this is a great opportunity to expand your offerings with something unique.
Expand your recuperator
Make your heat recovery unit even more comfortable. See available accessories.
Technical data
JZE class
AJZE for a temperate climate
-36,41kWh/(m²/year)
JZE for cold climates
-72,28kWh/(m²/year)
JZE for a warm climate
-13,23kWh/(m²/year)
Max flow rate (at 100 Pa)
1330m³/h
Sound power (gear I)
34,2dBA
Available static pressure at 1330 (m³/h)
100Pa
Energy consumption
671W
Nominal water consumption of the humidifier*
8,4ll/h
Preheater power - SMART HEATER
3000W
Secondary heater power - SMART HEATER
2000W
Power supply
230/50V/Hz
Diameter of the nozzles
315mm
Diameter of the connecting pipe
3/4cal
Efficiency according to EU 1254/2014, dT=13°C
78,3%
Height
1181mm
Width
1432mm
Depth
740mm
Weight
163kg
Filter class
ePM 10 50%* At 0.3 MPa water pressure and factory settings.
Dimensions
